PVC Layflat Hose
Respower
Product Photo
PVC Layflat Hose
Description:
PVC Layflat hose is a tough water discharge hoses made with a PVC cover and reinforced polyester yarn, The high tensile polyester yarn provides great durability and strength in all working situations. It is highly durable while maintaining graet flexibility and best suited for low--medium pressure applications.
Features:
Light weight, Good flexibility.
Corrosion resistant, anti-aging
Easy use & storage
Different colors available
Assemblies or cut lengths available.
Burst pressure 3 times working pressure.
Non-toxic, Non-smell
Application:
PVC layflat hose is designed for ligh and heavy duty applications, the hoses are most commonly used in agricultural equipment where continuous water flow through irrigation systems is required. Additional uses include water pump, pool & spa,construction, mines and marine.
STRONG STRUCTURE
Premium PVC tube & cover with high tensile polyester braiding, can work well in light & heavy duty applications. Excellent performance in corrosion,age and abrasion resistance
SUPERIOR ABILITY
The PVC layflat hose is light weight with good flexibility. It's non-smell and non-toxic,very easy to handle and storge in irrigation system or other watering systems
MUTIPILE CHOICES
There are optional diameters and length in terms of size, you can also choose different colors and assemblies.
WIDE APPLICATION
Commonly used in agricultural equipment where continuous water flow through irrigation systems is required. Other application include water pump, pool & spa,construction, mines and marine.
Product Parameters
I.D. | W.P.(MAX) | B.P.(MAX) | UNIT LENGTH | |
in. | mm | BAR | BAR | m/roll |
3/4 | 19.1 | 10 | 30 | 100 |
1 | 25.4 | 10 | 30 | 100 |
1 1/4 | 31.8 | 10 | 30 | 100 |
1 1/2 | 38.1 | 10 | 30 | 100 |
2 | 50.8 | 10 | 30 | 100 |
3 | 75.0 | 10 | 30 | 100 |
4 | 102.0 | 10 | 30 | 100 |
6 | 152.0 | 10 | 30 | 100 |
8 | 200.0 | 10 | 30 | 100 |
10 | 254.0 | 4 | 12 | 100 |
12 | 305.0 | 4 | 12 | 100 |
