Rubber Belt for Shot Blasting Machine
The track of a shot blasting machine consists of three layers. The outer layer is covered with rubber. This is in direct contact with the workpiece being cleaned and is struck by the steel shot, resulting in severe wear and tear and a high degree of destructive force.
一、Shot blasting machine classification
l Classified by structural form
1.1 Crawler Type Shot Blasting Machine
1.2 Hook Type Shot Blasting Machine
1.3 Drum Type Shot Blasting Machine
1.4 Through Type Shot Blasting Machine
1.5 Turntable Type Shot Blasting Machine
1.6 Chain Hanging Type Shot Blasting Machine
l Classification by application field
2.1 General Purpose Shot Blasting Machine
2.2 Special Shot Blasting Machine for Steel Structure
2.3 Shot Blasting Machine for Auto Parts
2.4 Shot Blasting Machine for Casting Cleaning
2.5 Stone Shot Blasting Machine
二、Core Components
Shot Blaster
Shot Recycling System
2.1 Hoist
2.2 Separator
2.3 Screw Conveyor
Blasting Chamber
Dust Removal System
Electrical Control System
Applicable scenarios
Type | Perimeter(mm) | Width(mm) | Thickness(mm) | aperture diameter(mm) |
Q324 | 2500 | 750 | 15 | 4 6 |
Q326 | 3400 | 1130 | 18 | 4 6 8 |
Q3210 | 4900 | 1400 | 20 | 10 12 |
Q3212 | 6000 | 1530 | 22 | 10 12 14 16 |
Q3220 | 5300 | 1850 | 22 | 10 12 14 16 |
Q3220 | 5850 | 1850 | 22 | 10 12 14 16 |
Q3220 | 6150 | 1850 | 22 | 10 12 14 16 |
Mainly suitable for surface shot peening treatment of various non-ferrous metal castings, stainless steel products, aluminum profiles, hardware tools, natural stone and other industries, it can highlight the true color of the metal, make the metal surface smooth and rust free, and achieve a matte effect
Transmission function: The track transmits the power of the motor to the working device of the shot blasting machine, such as the shot blasting wheel, pusher, etc. By rotating and pushing the track, the workpiece moves continuously in the shot blasting machine to achieve the effect of shot blasting treatment.
Bearing function: The track carries the weight of the workpiece during the shot blasting process, enabling it to move safely and stably inside the shot blasting machine. The track needs to have sufficient strength and rigidity to withstand the weight of the workpiece and the impact during the shot blasting process.
Protective effect: The track can protect other components inside the shot blasting machine from direct impact and wear of the workpiece. As a protective plate, it reduces direct friction and damage caused by the workpiece to the structure of the shot blasting machine.
The track of the shot blasting machine also needs to have sufficient rigidity and stability to ensure smooth movement of the workpiece during the shot blasting process.
