Features
1. Small elongation in use
2. High tensile strength
3. Good grooving performance
4. Small diameter of transmission roller
5. Good adhesion between rubber and wire rope
6. Uniform wire rope tension
7. X-ray detection available
8. Lower unit operating cost
9. Lightweight and more energy-saving
10. Intelligent
Technical Data
| Standard belt specification |
Belt
strength
(st-NO.) | Max Cord
diam
(mm) | composition |
Pitch
(mm) | Standard
working tension
(N/mm) | standard cover
Thickness t1t2
(mm) | Belt
weight(Kg/m²) | Min pulley
diam(mm) | cord
strength
KN/piece |
| St-630 | 3 | K6x7+IWS | 10 | 90 | 5x5 | 19.1 | 800 | 6.93 |
| St-800 | 3.5 | K6x7+IWS | 10 | 110 | 5x5 | 20.6 | 800 | 8.8 |
| St-1000 | 4 | K6x7+lWS | 12 | 140 | 6x6 | 24.7 | 800 | 13.2 |
| St-1250 | 4.5 | K6x7+WS | 12 | 175 | 6x6 | 25.4 | 800 | 16.5 |
| St-1600 | 5 | K6x19+IWS | 12 | 225 | 6x6 | 26 | 1000 | 21.12 |
| St-2000 | 6 | K6x19+IWS | 12 | 285 | 8x6 | 30 | 1000 | 26.4 |
| St-2500 | 7.2 | K6x19W+IWS | 15 | 355 | 8x6 | 32.2 | 1250 | 41.25 |
| St-3150 | 8.1 | K6x19W+IWS | 15 | 450 | 8x8 | 35.7 | 1400 | 51.98 |
| St-3500 | 8.6 | K6x19W+IWS | 15 | 500 | 8x8 | 44.9 | 1500 | 57.7 |
| St-4000 | 8.9 | K6x19W+IWS | 15 | 570 | 8x8 | 46.6 | 1600 | 66 |
| St-4500 | 9.7 | K6x19W+IWS | 16 | 645 | 8x8 | 49 | 1800 | 79.2 |
| St-5000 | 10.9 | K6x19W+IWS | 17 | 715 | 8.5x8.5 | 53.6 | 1800 | 93.5 |
| St-5400 | 11.3 | K6x19W+WS | 17 | 760 | 9x9 | 57.5 | 2000 | 101 |
