Manufacturer PVC Steel Wire Hose / Enhanced Pumping Hose

Share to:

Manufacturer PVC Steel Wire Hose / Enhanced Pumping Hose

This hose, with steel screwing inlaid, which with small bending radius, no smells, non-poison, light, transparent.

Availability:

Quantity:



Inquire Add to Basket

Model:
PVC Steel Wire Hose
Brand:
Respower

Product Description

Product Photos

PVC Steel Wire Reinforced Hose
Characteristics:
·This hose, with steel screwing inlaid, which with small bending radius, no smells, non-poison, light, transparent.
·It has good adaptability to hard weather conditions and minus pressure.
·Be enduring of high intensity, strong pulling force,and convenient for installation and transportation.
·Working Temperature: from -5ºC to +65ºC
Application:
·Widely used for drawing and conveying water, oil and powder in factories agriculture, engineering, food stuffs and sanitary lines. ·We can produce the high temperature hose up to +120ºC depends on the using environment.
Product Parameters

British Measurement	Metric Measurement			W.P.	B.P.	Weight
British Measurement	I.D.	Wall	Length	W.P.	B.P.	Weight
Inch	mm	Thickness	M/roll	Mpa	Mpa	Kg/m
3/8	Φ10	2.8-3.0	100	0.5	1.5	0.2
1/2	Φ13	2.8-3.0	100	0.5	1.5	0.23
5/8	Φ16	2.3-2.8	100	0.5	1.5	0.25
3/4	Φ19	2.5-2.8	50	0.5	1.5	0.3
3/4	Φ19	3.6-3.8	50	0.5	1.5	0.4
1	Φ25	1.5-1.7	50	0.35	1.05	0.25
1	Φ25	1.7-1.8	50	0.4	1.2	0.3
1	Φ25	2.6-2.8	50	0.45	1.35	0.4
1-1/4	Φ32	2.3-2.5	50	0.3	0.9	0.5
1-1/4	Φ32	3.2-3.5	50	0.4	1.2	0.7
1-3/8	Φ34	2.9-3.0	50	0.3	0.9	0.6
1-1/2	Φ38	2.2-2.3	50	0.2	0.6	0.5
1-1/2	Φ38	3.5-3.8	50	0.35	1.05	0.8
1-1/2	Φ38	4.2-4.5	50	0.45	1.35	0.1
	Φ40	3.0-3.5	50	0.25	0.75	0.7
1-3/4	Φ45	3.0-3.3	50	0.25	0.75	0.8
1-3/4	Φ45	3.6-3.7	50	0.35	1.05	1.0
2	Φ50	2.5-2.8	50	0.2	0.6	0.8
2	Φ50	3.2-3.3	50	0.25	0.75	1.0
2	Φ50	3.7-3.8	50	0.35	1.05	1.2
2	Φ50	4.8-4.9	50	0.4	1.2	1.4
2-3/8	Φ58	3.8-4.0	40	0.25	0.75	1.2
2-3/8	Φ58	4.2-4.5	40	0.25	0.75	1.4
2-1/2	Φ64	2.8-3.1	40	0.12	0.36	1.2
2-1/2	Φ64	3.5-3.7	40	0.18	0.54	1.6
2-1/2	Φ64	5.0-5.5	40	0.25	0.75	2.0
3	Φ75	3.8-4.0	40	0.18	0.54	1.8
3	Φ75	4.3-4.7	40	0.2	0.6	2.0
3	Φ75	5.3-5.5	40	0.3	0.9	2.5
3-1/2	Φ89	3.8-4.2	30	0.15	0.45	2.5
3-1/2	Φ89	5.5-6.0	30	0.2	0.6	3.0
4	Φ102	4.2-4.3	30	0.1	0.3	2.6
4	Φ102	5.0-5.3	30	0.15	0.45	3.0
4-1/2	Φ110	5.0-5.2	20	0.3	0.9	4.5
5	Φ127	5.0-5.4	20	0.3	0.9	5.0
6	Φ152	6.0-6.3	20	0.3	0.9	6.0

Remark:Specifications can be customized according to customer requirements. If you need other special specifications, please come to consult customer service

PVC Steel Wire Hose Water supply pipe pump pipe Pumping water pumping oil
